MIL-PRF-39016/53C
Life test requirements:
High level: 100,000 cycles.
Low level: 100,000 cycles plus 900,000 cycles mechanical life.
Part number: M39016/53- (dash number from table I and suffix letter designating failure rate level).
Qualification inspection:
Qualification inspection and sample size: See table II.
TABLE II. Qualification inspection and sample size. 1/
Single submission
Group submission
22 units plus 1 open unit for level L
M39016/53-011
22 units plus 1 open unit for level L
at C = 0 2/
at C = 0 2/
33 units plus 1 open unit for level M
33 units plus 1 open unit for level M
at C = 0 2/
at C = 0 2/
Qualification inspection as applicable
Qualification inspection as applicable.
M39016/53-001
2 units, each part number, qualification inspection
M39016/53-003
table, group II.
M39016/53-007
M39016/53-009
M39016/53-013
M39016/53-006
2 units, qualification inspection table, group II,
M39016/53-026
and shock, vibration, acceleration,
terminal strength, and seal.
1/ For retention of qualification or extension of qualification to low failure rate levels, all life test data accumulated
on MIL-PRF-39016/54 may be used in addition to MIL-PRF-39016/53 data. Prior to performance of retention
of qualification inspection testing; the relay manufacturer shall preselect the sampling plan.
2/ The number of units required for qualification testing will be increased as required in group IV, table II, MIL-
PRF-39016, if the relay manufacturer elects to test the number of units permitting one or more failures. Prior
to the performance of qualification inspection testing the relay, manufacturer shall preselect the sample size.
6
