MIL-PRF-39016/53C
Electrical data:
Insulation resistance: 1/ 10,000 megohms minimum, except the resistance between coil and case at high
temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage: 1/
Sea level
Altitude
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure, and between all
contacts in the energized and deenergized position - -
750
Between case, frame, or enclosure and coil(s)- - - - - - -
350
500
Between all contacts and coil(s)- - - - - - - - - - - - - - - - -
All terminals
750
Between open contacts in the energized and
to case
deenergized positions - - - - - - - - - - - - - - - - - - - - - -
500
Between contact poles - - - - - - - - - - - - - - - - - - - - - - -
750
Diode characteristics:
Maximum negative transient: 1.0 V.
Coil transient suppression: Applicable (Warning: Reverse polarity on coil terminals will destroy the diode).
Semiconductor in process screening: Applicable, visual inspection of semiconductors shall be in accordance
with MIL-STD-750, method 2074.
Environmental data:
Temperature range: -65°C to +125°C.
Vibration (sinusodial): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds maximum
for closed contacts and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts
(Applicable to qualification and group C testing only).
Shock (specified pulse): MIL-STD-202, method 213, test condition C (100 g). Contact chatter shall not exceed
10 microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Magnetic interference: Applicable.
Resistance to soldering heat: Applicable.
Acceleration: Applicable.
Physical:
Terminal strength: 1.5 ±0.2 pounds (pull).
Solderability: Applicable (except to gold plated terminals).
Terminal twist test: Applicable to wire leads.
1/ Connect coil leads together to avoid damage to diode.
