MIL-PRF-39016/45E
TABLE II. Qualification inspection and sample size. 1/
Single submission
Group submission
M39016/45-021
20 units plus 1 open unit for
20 units plus 1 open unit for level
level L at C = 0 1/
L at C = 0 1/
33 units plus 1 open unit for
33 units plus 1 open unit for level
level M at C = 0 1/
M at C = 0 1/
Qualification inspection as
Qualification inspection as
applicable
applicable.
M39016/45-010
2 units, qualification inspection
table, Q2, and shock, vibration,
acceleration, terminal
strength, and seal.
M39016/45-003
2 units, qualification inspection
M39016/45-009
table, Q2. 1 unsealed sample
unit.
M39016/45-015
M39016/45-027
1/
The number of units required for qualification testing will be increased as required in
Q5, MIL-PRF-39016, if the relay manufacturer elects to test the number of units
permitting one or more failures. Prior to performance of qualification inspection testing,
the relay manufacturer shall preselect the sampling plan.
Group B and C tests may be suspended with qualifying activity approval. The qualifying activity shall be notified of
any design and/or construction changes and shall impose additional testing requirements as necessary.
SUPERSESSION DATA: See table III.
TABLE III. Supersession data.
New PIN1/
Inactive PIN
M5757/76-
M39016/45-
008
001
014
002
020
003
026
004
009
013
015
014
021
015
027
016
011
017
017
018
023
019
029
020
1/
Complete part number shall contain suffix
letter L, M, P, or R to designate failure rate
level (see 3/ in table I). A part with any failure
rate supersedes the applicable MIL-R-5757
part.
