MIL-PRF-39016/45E
COIL DATA: (See table I).
Duty rating: Continuous.
Operate and bounce time: 7 ms maximum over temperature range with rated coil voltage.
Release time: Not applicable. Coil life: Not applicable.
ELECTRICAL DATA: 1/
Insulation resistance: 1,000 megohms minimum, except the resistance between coil and case at high temperature
shall be 500 megohms or greater.
Dielectric withstanding voltage:
Sea level
Altitude
V rms (60 Hz)
V rms\
(60 Hz)
Between case, frame, or enclosure and all contacts
in the energized and de-energized positions.
1,000
Between case, frame, or enclosure and coils.
500
350
Between all contacts and coils.
1,000
All terminals
Between open contacts in the energized and
to case
de-energized positions.
500
Between coils
500
Between contact poles.
1,000
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204, test condition D (except frequency shall be 10 to 2,500 Hz).
Contact chatter shall not exceed 10 microseconds maximum for closed contacts and 1 microsecond maximum
closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts, and 1 microsecond maximum closure for closed contacts, and 1
microsecond maximum closure for open contacts (applicable to qualification and group C testing only).
Shock (specified pulse): MIL-STD-202, method 213, test condition C (100 g's). Contact chatter shall not exceed
10 microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Magnetic interference: Applicable.
Resistance to soldering heat: Applicable.
Acceleration: Applicable.
Salt spray (corrosion): Applicable.
_______________
1/
(For qualification and group C tests only). During insulation resistance and dielectric withstanding voltage tests,
the relay shall be latched in each of the two positions.
4
