MIL-R-83726-14 Relays, Hybrid, Time Delay, On Operate, Type I, Class B, 10 Amperes, 4Pdt, Hermetically Sealed, Fixed Time, 0.100 To 300 Seconds

Pages 1 - 2 - 3 - 4 - 5 - 6

MIL-R-83726/140

Inches

.032

.138

.375

.38

1.187

1.531

2.34

0.81

3.51

9.53

9.7

30.15

38.89

59.4

NOTES:

1. 0imensions are in inches.

2. Unless otherwise specified, tolerances are ±.010 (0.25 mm) for three place decimals and

±.03 (0.8 mm) for two place decimals.

3. Metric equivalents are given for general information only.

4. Terminal numbers shall not appear on the relay header and there shall be affixed to the relay a permanent legible circuit diagram that identifies each terminal location specified.

FIGURE 1. Outline dimensions and configuration of relay - Continued.
