MIL-PRF-83726/31J
Part or Identifying Number (PIN): Consists of the prefix M83726/31-, a four digit dash number (time delay
expressed in milliseconds), and a suffix letter (P for plug-in; S for solder lug) as follows:
M
83726/31-
1001
P
Military
designation
Specification sheet number
The first three digits are significant; the fourth is the number
of zeros to follow the first three digits. The time is expressed
in milliseconds and converted to seconds. (See examples.)
Suffix letter. (Any relay numbered prior to the date of this specification shall be
considered interchangeable with same mounting type, store and issue.)
Examples:
M83726/31-1001P 0.1 to 1 second time delay, plug-in.
M83726/31-9002S 9 to 90 second time delay, solder lug.
NOTE: Time delay relays within the 0.1 second to 500 second delay range are available within a
one-decade range. The PIN represents the upper timing limit of each range.
Marginal notations are marked with vertical lines to indicate where changes from the previous issue were
made. This was done as a convenience only and the Government assumes no liability whatsoever for
any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the requirements
of this document based on the entire content irrespective of the marginal notations and relationship to the
last previous issue.
