MIL-PRF-83536/1B
Dielectric withstanding voltage 2/:
Sea level:
Coil to case
All other points
Initial:
1,000
1,000
After life:
750
750
Altitude:
At 80,000 feet:
250
250
At 300,000 feet:
500
500
Environmental characteristics:
Temperature range: -70°C to +125°C.
Shock (specified pulse): Applicable, MIL-STD-202, method 213, test condition C except peak value shall be
200 g's for 6 ±1 ms. Contact chatter shall not exceed 10 microseconds maximum for closed contacts and
1 microsecond maximum closure for open contacts.
Vibration (sinusoidal): Applicable, MIL-STD-202, method 204, 30 g's except frequency range shall be 70 to
3,000 Hz. Contact chatter shall not exceed 10 microseconds maximum for closed contacts and 1 microsecond
maximum closure for open contacts.
Vibration (random): Applicable to qualification and group C inspection. Test in accordance with MIL-STD-202,
2
method 214, test condition IG (0.4 g /Hz, 50 to 2,000 Hz). Contact chatter shall not exceed 10 microseconds
maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Acceleration: Applicable, except 15 g's.
Physical data:
Dimensions and configurations: See figure 1.
Weight: 0.034 pound (15.4 grams).
Terminal strength:
Solder hook terminals:
Pull force: 5 pounds ±0.5 pound.
Bend: Applicable.
Twist: Not applicable.
Solder pin terminals:
Pull force:
For .040 diameter terminals: 5 pounds ±0.5 pound.
For .050 diameter terminals: 10 pounds ±0.5 pound (applicable to polarizing pin only).
_____
2/ Dielectric may be improved by suitable insulation of terminals and wiring after installation.
9
