MIL-PRF-6106/15E
Vibration-random (for -004): Method 214A of MIL-STD-202.
Low level, performance: Test condition ID applies for a total test time of 30 minutes per axis.
High level, non-performance: Test condition IG applies for a total test time of 2 hours per axis.
High level, performance: Test condition IJ applies except the test frequency shall be the 500 to 2,000 Hz
frequency band of the specified curve and rolloff of -9 dB/OCT with an overall GRMS of 29.5. The total test
times shall be 30 minutes per axis.
Strength of terminals and mounting studs: See MIL-PRF-6106.
Insulation resistance: 100 megohms.
Dielectric withstanding voltage (sea level):
All terminals (initial and after life tests): 1,050 V rms.
Dielectric withstanding voltage (altitude):
All terminals (initial and after life tests): 500 V rms.
Maximum contact voltage drop initial: 0.150 volt.
After life test: 0.175 volt.
Overload current: 400 amperes dc.
Rupture current: 500 amperes dc.
Duty rating: Continuous.
Qualification by similarity: See MIL-PRF-6106.
Part or Identifying Number (PIN): M6106/15 (and a dash number from table III).
TABLE III. Dash number and operating characteristics.
Dash
no.
(V dc) 1/
-001
-002
-003
-004
25 4/
40 4/
2 4/
1/
CAUTION: Use of any coil voltage less than nominal voltage will compromise the operation of the relay.
2/
At 25°C.
3/
Pickup, hold, and dropout voltages shown are for test purposes only and shall not be used for design criteria.
4/
Over the temperature range.
5/
With nominal coil voltage.
6/
Relay shall not operate or be damaged by reverse coil polarity.
