MIL-PRF-39016/6L
ELECTRICAL DATA:
Insulation resistance: 10,000 MΩ minimum.
Dielectric withstanding voltage:
Sea level
Altitude
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure and all
contacts in the energized and de-energized
1,000
350
positions.
All terminals
Between case, frame, or enclosure and coil.
500
to case
Between all contacts and coil
1,000
Between open contacts in the energized and de-
energized positions
500
Between contact poles
1,000
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microsecond maximum
for closed contacts, and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microsecond maximum for closed contacts, and 1 microsecond maximum closure for open contacts. (Applicable
to qualification and group C testing only).
Shock (specified pulse): MIL-STD-202, method 213, test condition C (100 G). Contact chatter shall not exceed
10 microsecond maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Magnetic interference: Applicable.
Resistance to soldering heat: Applicable.
Acceleration: Applicable.
PHYSICAL DATA:
Terminals: See figure 1 and table I.
Terminal strength: 3 ±0.3 pounds pull.
Terminal solderability: Applicable.
Terminal twist test: Applicable to wire lead terminals.
Dimensions and configuration: See figure 1.
Weight: 13 grams (0.46 ounce) maximum.
Identification marking (full): Applicable.
Seal: Hermetic.
5
