MIL-PRF-39016/48D
QUALIFICATION INSPECTION:
Qualification inspection and sample size: See table II.
TABLE II. Qualification inspection and sample size. 1/
Single submission
Group submission
M39016/48-002
24 units plus 1 open unit.
24 units plus 1 open unit for
level L at C = 0 2/
For level L at C = 0 2/
33 units plus 1 open unit for
33 units plus 1 open unit.
level M at C = 0 2/
For level M at C = 0 2/
Qualification inspection as
Qualification inspection as
applicable
applicable
M39016/48-001
2 units, each part number,
qualification inspection
table, Q1.
M39016/48-003
2 units, qualification
inspection table , Q1,
and shock, vibration,
acceleration, terminal
strength, and seal.
1/ For retention of qualification or extension of qualification to lower failure rate levels all
39016/48 data. Prior to retention of qualification inspection testing; the relay
manufacturer shall preselect the sample size.
2/ The number of units required for qualification testing will be increased as required in
Q5, of MIL-PRF-39016, if the relay manufacturer elects to test the number of units
permitting one or more failures. Prior to performance of qualification inspection testing;
the relay manufacturer shall preselect the sampling plan.
QUALIFICATION INSPECTION:
Qualification inspection (reduced testing): See table III.
If the relays produced for MIL-PRF-39016/48 are similar in construction and design except for the coil and
residual shim to the relays produced for MIL-PRF-39016/47 and MIL-PRF-39016/48, then reduced testing for
qualification of MIL-PRF-39016/48 relays may be performed concurrent with or subsequent to successful
qualification of MIL-PRF-39016/47 relays.
TABLE III. Qualification inspection (reduced testing).
Examination or test
2 units each coil voltage: Q1 of qualification
inspection table.
1 unsealed sample unit : Internal examination.
6
