INCH-POUND
MIL-PRF-39016/48D
17 April 2013
SUPERSEDING
MIL-PRF-39016/48C
27 August 2006
PERFORMANCE SPECIFICATION SHEET
RELAYS, ELECTROMAGNETIC, ESTABLISHED RELIABILITY, DPDT,
LOW LEVEL TO 0.5 AMPERE (.100 D.I.P. TERMINAL SPACING)
ONE-TENTH SIZE, SENSITIVE, MONOSTABLE
Inactive for new design after 8 July 2002.
This specification sheet is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-39016.
.
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5945
