MIL-PRF-39016/38C
COIL DATA: (See table I).
Operate time: 4.0 ms maximum over temperature range with rated coil voltage.
Release time: 6.0 ms maximum over temperature range from rated coil voltage.
ELECTRICAL DATA:
Insulation resistance: 1/ 10,000 megohms minimum, except the resistance between coil and case at
high temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage: 1/
Sea level
Altitude
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure, and all contacts in the
energized and de-energized positions: ----------------------------
750
350
Between case, frame, or enclosure and coil: ---------------------
500
All terminals
Between all contacts and coil: ----------------------------------------
750
to case
Between open contacts in the energized and deenergized
positions: ------------------------------------------------------------------
500
Between contact poles: ------------------------------------------------
750
DIODE CHARACTERISTICS: 2/
Maximum negative transient: 1.0 volt.
Breakdown voltage: 100 V dc, at 10 microamperes (µA).
Maximum leakage current: 1 µA at 50 V dc.
Coil transient suppression: Applicable.
Semiconductor in-process screening: Applicable, visual inspection of semiconductors shall be in
accordance with MIL-STD-750, method 2074.
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds
maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
1/ Insulation resistance and dielectric withstanding voltage tests must always precede all other specified
measurements. Connect all coil terminals together to avoid damage to the diodes.
2/ In all tables relating to qualification testing and group A testing, delete coil resistance and substitute the
following test: Diode breakdown and block integrity with applicable voltage applied to the relay coil circuit in the
reverse direction, monitor leakage current with dc microammeter or oscilloscope. Leakage current shall not
exceed the specified value.
4
