INCH-POUND
MIL-PRF-39016/38C
5 August 2003
SUPERSEDING
MIL-PRF-39016/38B
20 July 1988
PERFORMANCE SPECIFICATION SHEET
RELAYS, ELECTROMAGNETIC, ESTABLISHED RELIABILITY, DPDT,
LOW LEVEL TO 2 AMPERES (0.150-INCH TERMINAL SPACING),
WITH INTERNAL DIODES FOR COIL TRANSIENT SUPPRESSION AND
REVERSE POLARITY PROTECTION
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist
of this specification and the latest issue of MIL-PRF-39016.
FIGURE 1. Dimensions and configuration.
AMSC N/A
1 of 7
FSC 5945
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
