MIL-PRF-39016/37D
COIL DATA: (see table I).
Operate time: 4.0 ms maximum over temperature range with rated coil voltage.
Release time: 6.0 ms maximum over temperature range from rated coil voltage.
ELECTRICAL DATA:
Insulation resistance: 1/ 10,000 megohms minimum, except the resistance between coil and case at high
temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage: 1/
Sea level
Altitude
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure, and all contacts in the energized and de-energized
positions: .................................................................................................................
750
Between case, frame, or enclosure and coil:....................................................................
500
350
Between all contacts and coil:.......................................................................................
750
All terminals
Between open contacts in the energized and deenergized positions:....................................
500
to case
Between contact poles:................................................................................................
750
DIODE CHARACTERISTICS:
Maximum negative transient: 1.0 volt.
Coil transient suppression: Applicable (Warning reverse polarity on coil terminals will destroy the diode).
Semiconductor in-process screening: Applicable, visual inspection of semiconductors shall be in accordance with
MIL-STD-750, method 2074.
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds maximum
for closed contacts, and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts (applicable to
qualification and group C testing only).
Shock (specified pulse): MIL-STD-202, method 213, test condition C (100 g's). Contact chatter shall not exceed
10 µs maximum for closed contacts, and 1 µs maximum closure for open contacts.
-----
1/ Insulation resistance and dielectric withstanding voltage tests must always precede all other specified
measurements. Connect all coil terminals together to avoid damage to the diode.
4
