MIL-PRF-39016/29G
QUALIFICATION INSPECTION:
Qualification inspection and sample size: See table II.
TABLE II. Qualification inspection and sample size. 1/
Single submission
Group submission
M39016/29-053
18 units plus 1 open unit for
18 units plus 1 open unit for
level L at C = 0 2/
level L at C = 0 2/
33 units plus 1 open unit for
33 units plus 1 open unit for
level M at C = 0 2/
level M at C = 0 2/
Qualification inspection as
Qualification inspection as
applicable
applicable
M39016/29-049
2 units each PIN
M39016/29-050
Qualification inspection, Q1.
M39016/29-051
M39016/29-052
M39016/29-054
M39016/29-055
M39016/29-056
M39016/29-057
M39016/29-058
M39016/29-059
M39016/29-060
M39016/29-073
1 unit terminal strength and
terminal solderability
1/ For retention of qualification or extension of qualification to lower failure rate
levels, all life test data accumulated on MIL-PRF-39016/30 may be used in
addition to MIL-PRF-39016/29 data. Prior to performance of qualification or
extension of qualification testing, the relay manufacturer shall preselect the
sampling plan.
2/ The number of units required for qualification testing shall be increased as
required in Q5, MIL-PRF-39016, if the relay manufacturer elects to test the
number of units permitting one or more failures. Prior to performance of
qualification inspection testing, the relay manufacturer shall preselect the
sampling plan.
Initial qualification of relays supplied with spreader mounting pads (-061 through -072) shall be tested as
specified below:
Perform the following tests as specified in the qualification inspection table of MIL-PRF-39016, in the order
shown below:
Before installation of spreader mounting pad; screening, visual and mechanical inspection (internal),
thermal shock, resistance to solvents, vibration (sinusoidal), vibration (random), shock (specified pulse),
acceleration, terminal strength, magnetic interference (when specified), capacitance (when specified),
coil life (applicable to continuous duty relays only), resistance to soldering heat, salt spray (corrosion),
overload (applicable to high level relays only), life, terminal strength, and intermediate current.
8
