MIL-PRF-39016/29G
COIL DATA: See table I.
Operate time: 2.0 ms maximum over temperature range with rated coil voltage.
Release time: Not applicable.
ELECTRICAL DATA: 1/
Insulation resistance: 10,000 megohms minimum at 500 V dc, except the resistance between coil and case
at high temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage:
Post
Sea level
intermediate
Altitude
current life test
V rms (60
V rms (60 Hz)
Sea level V
Hz)
rms (60 Hz)
Between case, frame, or enclosure and all contacts
in the energized and de-energized positions.
500
500
125
Between case, frame, or enclosure and coils.
500
500
All terminals
Between all contacts and coils.
500
500
to case
Between open contacts in the energized and
de-energized positions.
500
375
Between contact poles.
500
500
Between coils of dual coil relays.
500
500
DIODE CHARACTERISTICS: 2/
Maximum transient voltage: 1.0 volt.
Coil transient suppression: Applicable.
Semiconductor in-process screening: Applicable, visual inspection of semiconductors shall be in
accordance with MIL-STD-750, method 2073, or 2074.
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds
maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts
(applicable to qualification and group C testing only).
1/ Dielectric withstanding voltage and insulation resistance are not applicable between coils and case or from
coil to coil on figure 1 relays.
2/ WARNING: Reverse polarity on coil terminals will destroy diode.
