MIL-PRF-39016/22E
TABLE II. Qualification inspection and sample size. 2/
Single submission
Group submission
M39016/22-004
20 units plus 1 open unit for level L
20 units plus 1 open unit for level L
at C = 0 1/
at C = 0 1/
33 units plus 1 open unit for level M
33 units plus 1 open unit for level M
at C = 0 1/
at C = 0 1/
Qualification inspection as applicable.
Qualification inspection as applicable
2 units, qualification inspection table,
M39016/22-023
Q1.
2 units, qualification inspection table,
M39016/22-013
Q1, and shock, vibration,
acceleration, terminal strength and
seal
1/ The number of units required for qualification testing shall be increased as required in Q5, table II,
MIL-PRF-39016, if the relay manufacturer elects to test the number of units permitting one or more failures.
Prior to performance of qualification inspection testing, the relay manufacturer shall preselect the sampling
plan.
2/ For retention of qualification or extension of qualification to lower failure rate levels, all life test data accumulated
on MIL-PRF-39016/6 may be used in addition to MIL-PRF-39016/22 data. Prior to performance of retention of
qualification testing, the relay manufacturer shall preselect the sampling plan.
QUALIFICATION INSPECTION (reduced testing): See table III.
If the relays produced for MIL-PRF-39016/22 are similar in construction and design except for the coil to the relays
produced for MIL-PRF-39016/6, then reduced testing for qualification of MIL-PRF-39016/22 relays may be
performed concurrent with or subsequent to successful qualification of MIL-PRF-39016/6 relays.
TABLE III. Qualification inspection (reduced testing).
Examination or test
2 units each coil voltage: Q1 of qualification inspection
table.
1 unsealed sample unit for internal examination.
6
