MIL-PRF-39016/22E
Electrical data:
Insulation resistance: 10,000 megohms minimum.
Dielectric withstanding voltage:
Sea level
Altitude
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure, and between all
1,000
contacts in the energized and deenergized positions
500
350
Between case, frame, or enclosure and coil(s) - - - - - - -
1,000
All terminals
Between all contacts and coil(s) - - - - - - - - - - - - - - - - -
to case
Between open contacts in the energized and
500
deenergized positions - - - - - - - - - - - - - - - - - - - - -
1,000
Between contact poles - - - - - - - - - - - - - - - - - - - - - - -
Coil transient characteristics: 1/
Maximum negative transient: See table I.
Environmental data:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 µs maximum for closed
contacts, and 1 µs maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10 µs
maximum for closed contacts, and 1 µs maximum closure for open contacts. Applicable to qualification and
group C testing only.
Shock (specified pulse): MIL-STD-202, method 213, test condition C (100 g's). Contact chatter shall not
exceed 10 µs maximum for closed contacts and, 1 µs maximum closure for open contacts.
Magnetic interference: Applicable.
Resistance to soldering heat: Applicable.
Acceleration: Applicable.
____________
1/ The following test shall be added to all qualification and group A testing performed on relays supplied to this
specification. In all tables, sequence after coil resistance. Coil transient suppression: Apply rated voltage to coil
using a cathode ray oscilloscope to monitor the voltage across the relay coil, instantaneously remove the coil
voltage (or current) with a mercury switch and observe the monitor to verify that any transient generated does not
exceed the specified value. Repeat the test applying opposite polarity to the coil. For qualification only, legible
photographs are required.
4
