MIL-PRF-39016/21H
Inches
mm
Ltr
Min
Max
Min
Max
A
.275
.335
6.99
8.51
B
---
.375
---
9.53
C
.016
.019
0.41
0.48
D
.025
.045
0.64
1.14
E
.190
.210
4.83
5.33
F
.028
.034
0.71
0.86
G
---
.370
---
9.40
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.010 (0.25 mm).
4. Terminal numbers shown above are for reference only. Numbers do not appear on relay.
5. Relays shall have a plus (+) sign placed on the circuit diagram as shown.
6. Coil symbol optional in accordance with MIL-STD-1285.
7. Circuit diagram shown on part is the terminal view.
FIGURE 1. Dimensions and configuration - Continued.
2
