MIL-PRF-39016/15L
COIL DATA: See table I.
Operate time: 2.0 ms maximum over temperature range with rated coil voltage.
Release time: 4.0 ms maximum over temperature range from rated coil voltage.
ELECTRICAL DATA:
Insulation resistance: 1/ 10,000 megohms minimum at 500 V dc, except the resistance between coil and case at
high temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage: 1/
Post
Sea level
intermediate
Altitude
V rms
current life test
V rms (60 Hz)
(60 Hz)
sea level
V rms (60 Hz)
Between case, frame, or enclosure and all
contacts in the energized and de-energized
500
500
125
positions.
All terminals
Between case, frame, or enclosure and coils.
500
500
to case
Between all contacts and coils.
500
500
Between open contacts in the energized and de-
energized positions.
500
375
Between contact poles.
500
500
Between coils of dual coil relays.
N/A
N/A
DIODE CHARACTERISTICS: 2/
Maximum negative transient: 1.0 volt.
Coil transient suppression: Applicable.
Semiconductor in process screening: Applicable, visual inspection of semiconductors shall be in accordance
with MIL-STD-750, method 2073 or 2074.
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds maximum
for closed contacts, and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Applicable to qualification and group C testing only.
1/ Connect coil leads together to avoid damage to the diode.
2/ Warning: Reverse polarity on coil terminals will destroy diode.
6
