MIL-R-83726/23D
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.010 (0.25 mm) for three place decimals and
±.03 (0.8 mm) for two place decimals.
4. Terminal numbers shall not appear on the relay header. There shall be affixed to the relay a permanent, legible circuit diagram that identifies each terminal location specified.
FIGURE 1. Dimensions and configurations - Continued.
2
