MIL-PRF-83726/36D
PHYSICAL REQUIREMENTS:
Dimensions and configuration: See figure 1.
Mating socket: MIL-DTL-12883/40-06, MIL-DTL-12883/40-12, MIL-DTL-12883/40-18, or
MIL-DTL-12883/40-24. (CAUTION: Consideration should be given to ambient temperature and
current requirements when using wire barrels size 20.)
Terminations: See figure 1.
Terminal strength: 3 pounds pull.
Weight: 3.0 ounces maximum.
Marking: See MIL-PRF-83726. In addition, relays shall be marked with the ESDS identifier as
specified in MIL-STD-1285.
Part or Identifying Number (PIN): Consists of the prefix M83726/36-, a four digit dash number (time
delay expressed in milliseconds), and a suffix letter (P for plug-in; S for solder lug):
M
83726/36-
1001
P
Military
designation
Specification sheet number
The first three digits are significant; the fourth is the number
of zeros to follow the first three digits. The time is expressed
in milliseconds and converted to seconds. (See examples.)
Suffix letter. (Any relay numbered prior to the date of this specification shall be
considered interchangeable with same mounting type, store and issue.)
Examples:
M83726/36-1001P 1 second time delay, plug-in.
M83726/36-9002S 90 second time delay, solder lug.
NOTE: Time delay relays within the 0.1 second to 600 second delay range are available.
The margins of this specification are marked with vertical lines to indicate modifications generated by this
amendment. This was done as a convenience only and the Government assumes no liability whatsoever
for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations.
Referenced documents. In addition to MIL-PRF-83726, this document references the following:
5
