MIL-PRF-83726/35D
REQUIREMENTS:
OPERATING REQUIREMENTS:
Timing action: Delay-on-operate.
Time delay: Fixed; select from 0.1 second to 600 seconds.
Timing accuracy: 10 percent of nominal value. (The accuracy requirement applies for any
combination of operating temperature and voltage. Add 10 ms for timing less than 1 second.)
Recycle time: 50 milliseconds maximum.
Power interrupt: 500 microseconds. (Transient and power loss specifications are based on a
maximum duty cycle of 1/50.)
Operating current: 150 mA maximum at 25°C.
INPUT REQUIREMENTS:
Input voltage range: 20 V dc to 30 V dc. (Minimum high temperature test 21 V dc, minimum
continuous current test 23.5 V dc.)
Duty rating: Continuous.
Polarity protection: The timer shall be inoperative during, and undamaged by, reversal of the polarity
of the operating voltage.
OUTPUT REQUIREMENTS: (At +25°C, unless otherwise specified.)
Configuration: 4PDT.
Life: See table I.
TABLE I. Life load ratings (relay case grounded).
Amperes
Amperes
Type of load
Life (cycles)
28 V dc
115/200 V ac 400 Hz
10
10
Resistive
100,000
8
8
Inductive
20,000
4
4
100,000
Motor
2
2
100,000
Lamp
---
100,000
---
Low level 1/
1/ Contact load 10 µA to 50 µA at 10 mV to 50 mV (dc or peak ac).
5
