MIL-PRF-83726/35D
Inches
Mm
Ltr
Min
Max
Min
Max
S
.190
.210
4.83
5.33
T
.061
.064
1.55
1.63
U
.045
.055
1.14
1.40
V
.260
.280
6.60
7.11
W
.290
.310
7.37
7.87
X
.490
.510
12.45
12.95
Y
.061
.063
1.55
1.60
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.010 (0.25 mm) for three place decimals and .03 inch
(0.76 mm) for two place decimals.
4. Terminal numbers shall not appear on the relay header and there shall be a legible circuit
diagram on the relay which identifies each terminal location specified.
5. Gasket material: The gasket material shall be of such quality to ensure the relay meets all the
performance requirements of this specification. Silicone rubber gasket SAE-AMS3332, shore
hardness 15 to 35 has been considered acceptable.
6. Terminal composition: The terminal composition shall be of such quality to ensure the relay meets
all the performance requirements of this specification. Gold in accordance with SAE-AMS2422 or
ASTM-B488, Type 3; underplating: nickel, 50 to 150 microinches thick; has been considered
acceptable.
7. Terminals Y1 and Y2 are not used.
FIGURE 1. Outline dimensions and configuration of relay - Continued.
