MIL-PRF-83726/28K
Part or Identifying Number (PIN): Consists of the prefix M83726/28-, a four digit dash number (time
delay expressed in milliseconds), and a suffix letter (P for plug-in, S for solder lug):
M
83726/28-
1001
P
Military designation
Specification sheet number
The first three digits are significant; the fourth is the
number of zeros to follow the first three digits. The time
is expressed in milliseconds and converted to seconds.
(See examples.)
Suffix letter. (Any relay numbered prior to the date of this specification shall
be considered interchangeable with same mounting type, store and issue.)
Examples:
M83726/28-1001P 1 second time delay, plug-in.
M83726/28-9002S 90 second time delay, solder lug
NOTE: Time delay relays within the 0.1 second to 500 second delay range are available.
The margins of this specification are marked with vertical lines to indicate where changes from the previous issue
were made. This was done as a convenience only and the Government assumes no liability whatsoever for any
inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the requirements of this
document based on the entire content irrespective of the marginal notations and relationship to the last previous
issue.
Referenced documents. In addition to MIL-PRF-83726, this document references the following:
Custodians:
Preparing activity:
Navy - EC
DLA - CC
Air Force - 85
DLA CC
(Project 5945-2013-006)
Review activities:
Navy - OS
Air Force 19
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.dla.mil.
6
