MIL-PRF-83726/20F
Acceleration: 100 g's.
Seal: MIL-STD-883, method 1014, condition B and condition C.
Moisture resistance: MIL-STD-202, method 106.
PHYSICAL REQUIREMENTS:
Dimensions and configurations: See figure 1.
Terminations: See figure 1.
Terminal strength: 3 pounds pull.
Weight: 0.5 ounce.
Marking: Marking shall be in accordance with MIL-PRF-83726. In addition, relays shall be marked with the
ESDS identifier as specified in MIL-STD-1285.
Part or Identifying Number (PIN): The PIN shall be as follows: Consists of the prefix M83726/20-, a four digit
dash number (time delay expressed in milliseconds), and a suffix letter (W for printed circuit mounting; A for
flange mounting):
M
83726/20-
1001
W
Military designation
Specification sheet number
The first three digits are significant; the fourth is the number of zeros
to follow the first three digits. The time is expressed in milliseconds
and converted to seconds. (See examples.)
Suffix letter. (Any relay numbered prior to the date of this specification shall be considered
interchangeable with same mounting type, store and issue.)
Examples:
M83726/20-1001W 1 second time delay, printed circuit mounting
M83726/20-9002A 90 second time delay, flange mounting
NOTE: Time delay relays within the 0.05 second to 500 second delay range are available.
CHANGES FROM PREVIOUS ISSUE: The margins of this specification are marked with a vertical line to indicate
where changes from the previous issues were made. This was done as a convenience only and the Government
assumes no liability whatsoever for an inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal notations and
relationship to the last previous issue.
Referenced documents. In addition to MIL-PRF-83726, this document references the following:
5
