INCH-POUND
MIL-PRF-83726/20F
10 June 2013
SUPERSEDING
MIL-PRF-83726/20E
23 June 2008
PERFORMANCE SPECIFICATION SHEET
RELAY, SOLID-STATE, TIME DELAY (ON OPERATE), TYPE I,
CLASS C, SPST, 250 MILLIAMPERES, FIXED TIME, 0.05 TO 500 SECONDS
This specification is approved for use by all
Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-83726.
Inactive For New Design After 15 November 2002.
FIGURE 1. Outline drawing and dimensions.
AMSC N/A
FSC 5945
