MIL-PRF-83536/23A
Dielectric withstanding voltage 2/:
Coil to case
Coil to coil
All other points
Sea level:
Initial:
500
500
1,250
After life:
350
350
1,000
Altitude:
At 80,000 feet:
250
250
350
At 300,000 feet:
500
500
500
Environmental characteristics:
Temperature range: -70°C to +125°C.
Maximum altitude rating: 300,000 feet.
Shock (specified pulse): Applicable, MIL-STD-202, method 213, test condition C 200 g's for 6 ±1 ms, except
horizontal flange mount peak g value shall be 100 g's for 6 ±1 ms. Contact chatter shall not exceed 10
microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Vibration (sinusoidal): Applicable, MIL-STD-202, method 204, 30 g's, except frequency range shall be 70 to
3,000 Hz. Horizontal flange shall be 20 g's, 57 to 3,000 Hz. Contact chatter shall not exceed 10 microseconds
maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Vibration (random): Applicable to qualification and group C inspection. Test in accordance with MIL-STD-202,
2
method 214, test condition IG (0.4 g /Hz, 50 to 2,000 Hz), for horizontal flange mount test condition IE (0.2
2
g /Hz). Contact chatter shall not exceed 10 microseconds maximum for closed contacts and 1 microsecond
maximum closure for open contacts.
Acceleration: Applicable, except 15 g's.
Physical data:
Dimensions and configurations: See figure 1.
Weight: 0.068 pound (30.87 grams).
Terminal strength:
Solder hook terminals:
Pull force: 5 pounds ±0.5 pound.
Bend: Applicable.
Twist: Not applicable.
Solder pin terminals:
Pull force:
For .030 diameter terminals: 3 pounds ±0.3 pound.
For .062 diameter terminals: 10 pounds ±1.0 pound.
2/ Dielectric may be improved by suitable insulation of terminals and wiring after installation.
9
