MIL-PRF-6106/9E
Initial
After life tests
28 V dc
115 V ac
28 V dc
115 V ac
Coil to case - - - - - - - - - - - - - - - - - - - - -
1250
1500
1000
1125
Auxiliary contacts - - - - - - - - - - - - - - - - -
1250
1250
1000
1000
Across open power contacts - - - - - - - - -
1250
1250
625
625
All other points - - - - - - - - - - - - - - - - - - -
1800
1800
1350
1350
Dielectric withstanding voltage (altitude) - 1 minute.
28 V dc
115 V ac
Coil to case - - - - - - - - - - - - - - - - -
500
500
Auxiliary contacts - - - - - - - - - - - - -
500
500
All other points - - - - - - - - - - - - - - -
700
700
Maximum contact drop, initial .150 volt.
After life test .200 volt.
NO (V ac)
NC (V ac)
Overload current
320
320
Rupture current
400
400
Duty rating: Continuous.
RFI specification (applicable to coil circuits of ac operated relays): MIL-STD-461.
Part number M6106/9- (dash number from table I).
Qualification by similarity: See MIL-PRF-6106.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate
the requirements of this document based on the entire content irrespective of the marginal notations and
relationship to the last previous issue.
1/ Number of rupture cycles after mixed loads test - 5.
Referenced documents. In addition to MIL-PRF-6106, this document references the following:
5
