MIL-PRF-6106/9E
Inches
mm
Inches
mm
Inches
mm
.010
0.25
.309
7.86
1.890
48.01
.02
0.51
.375
9.53
1.900
48.26
.028
0.71
.440
11.18
2.000
50.80
.032
0.81
.600
15.24
2.115
53.72
.063
1.60
.625
15.88
2.313
58.75
.148
3.76
1.000
25.40
2.40
60.96
.186
4.72
1.060
26.92
2.500
63.50
.240
6.10
1.375
35.18
3.032
77.01
.250
6.35
1.74
44.20
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is .031 (0.79 mm).
4. Weights include cover, barriers, and terminal hardware.
5. When using relay at rated 60 amps, the use of lugs per Burndy part number YAEV6C-G8 or equal is
recommended.
6. Terminal temperature rise under continuous current conditions is 95C maximum.
FIGURE 1. Relay, outline drawing - Continued.
