MIL-PRF-6106/47A
ELECTRICAL CHARACTERISTICS:
Insulation resistance, minimum:
Initial: 100 megohms.
After life or environmental: 50 megohms.
Dielectric strength:
1 Minute
Test points
1050 Volts
Contacts to case
1050 Volts
Contacts to coil
1050 Volts
Coil to case
1050 Volts
Between open contacts
Contact drop, maximum:
Initial: 0.15 volt.
After life test: 0.175 volt.
Overload current: 4,000 amperes for 20 cycles.
Rupture current: 10,000 amperes for 20 cycles.
Part number: D6106/47- (dash number from table II).
TABLE II. Nomenclature.
-001
Figure 1
Relay
-002
Figure 2
Mounting bracket
REQUIREMENTS: (Mounting bracket, see figure 2)
Material: Aluminum.
Finish: Paint, olive.
Weight: 1.2 pounds (0.54 Kg).
4
