MIL-PRF-6106/47A
CONTACT DATA:
Rated contact load: See table I.
TABLE I. Rated contact load (28 V dc).
Type of load
Life operating cycles
Load
x 103
(Amperes)
Resistive
10
1000
Inductive
5
250
Motor
5
500
Mechanical life
20
250
PHYSICAL CHARACTERISTICS:
Dimensions and configurations: See figures 1 and 2.
Material: Steel, corrosion resistant, seamless, or cold drawn tube.
Finish: Paint, olive.
Weight:
Relay: 4.2 kilograms maximum (9.1 pounds).
Terminals: See figure 1.
ENVIRONMENTAL CHARACTERISTICS:
Temperature range: -55°C to +74°C.
Shock:
Energized: MIL-STD-202, test method 213, test condition A, 50 G's.
+
Deenergized: MIL-STD-202, test method 213, test condition A, 50 G's (except Z axis, 30 G's).
Vibration:
Energized: MIL-STD-202, test method 204, test condition D, 20 G's.
Deenergized: MIL-STD-202, test method 204, test condition C, 10 G's.
Acceleration: 15 G's.
