MIL-PRF-6106/26G
TABLE I. Rated contact load (amperes per pole) (case grounded).
Life
oper-
28 V dc
115 V ac, 1 phase
115/200 V ac, 3 phase
Type of load
ating
Main
Aux
Main
Aux
Main
Aux
cycles
NO
NC
NO
NC
400
50/60
400
50/60
400
50/60
400
50/60
3
X 10
Resistive
50
50
50
5
5
65
---
5
---
---
---
---
---
Inductive
50
---
---
3
3
65
---
3
---
---
---
---
---
Inductive
20
50
50
---
---
---
---
---
---
---
---
---
---
Motor
---
---
---
---
---
---
---
---
---
---
---
---
---
Lamp
---
---
---
---
---
---
---
---
---
---
---
---
---
Transfer, load
---
---
---
---
---
---
---
---
---
---
---
---
---
Mechanical life
Reduced
---
---
---
---
---
---
---
---
---
---
---
---
---
current
Intermediate
APPLICABLE PER SPECIFICATION
current
REQUIREMENTS:
COIL DATA:
Nominal operating voltage: 28 V dc.
Maximum operating voltage: 29 V dc.
Pickup voltage: 15 V dc, maximum, at 25C.
Dropout voltage: 1.5 at 25C.
Hold voltage: 7 V dc at 25C.
Duty: continuous.
Coil current: 0.280 ampere, maximum, at 28 V dc, 25C.
OPERATIONAL DATA:
Operate time: 35 milliseconds maximum with nominal coil voltage.
Dropout time: 25 milliseconds maximum from nominal coil voltage.
Contact load: See table I.
Contact bounce time: 5 milliseconds, maximum.
Contact drop: 150 millivolts, maximum, initially
175 millivolts, maximum, after life test.
Overload current: 400 amperes ac, 125 amperes dc.
Rupture current: 500 amperes ac, 150 amperes dc.
3
