MIL-PRF-6106/20D
Qualification by similarity: If the relays produced in accordance with this specification sheet are similar in design
and construction to those covered by MIL-PRF-6106/19 (except for the coils), then reduced qualification by
similarity is authorized. Manufacturers shall be qualified to MIL-PRF-6106/19 and MIL-PRF-83536. Qualification
by similarity requirements are listed in table III.
TABLE III. Qualification by similarity.
Inspection
Number of units
Group A acceptance tests
7 1/
Vibration 2/
Resistive load, ac
2
Group A acceptance tests
Shock 2/
2
Inductive load, dc
Group A acceptance tests
Acceleration 2/
3
Intermediate current 3/
Group A acceptance test
1/ Four units of dash number -002 and three units of dash number -003.
All seven relays shall receive group A acceptance testing in accordance
with MIL-PRF-6106. The seven relays shall then be subdivided into
three groups as shown above for the remaining inspections.
2/ One unit of dash number -002 and one unit of dash number -003.
3/ Three units required for mixed loads testing.
7
