INCH-POUND
MIL-PRF-6106/12F
1 November 2011
SUPERSEDING
MIL-PRF-6106/12E
23 April 2001
PERFORMANCE SPECIFICATION SHEET
RELAY, ELECTROMAGNETIC (TYPE I), MAGNETIC LATCH,
25 AMPERES, 3PNO MAIN CONTACTS, WITH 2 AMPERE 1PDT
AUXILIARY CONTACTS, HERMETICALLY SEALED
Inactive for new design after 15 November 2002. No superseding document.
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the relay described herein shall consist of this specification and the MIL-PRF-6106.
FIGURE 1. Relay, outline drawing.
AMSC N/A
FSC 5945
