MIL-PRF-6106/10F
Dielectric withstanding voltage (sea level): 2 to 5 seconds.
Initial
After life tests
28 V dc
115 V ac
28 V dc
115 V ac
Coil to case - - - - - - - - - - - - - - - - - - - - -
1,250
1,500
1,000
1,125
Auxiliary contacts - - - - - - - - - - - - - - - - -
1,250
1,250
1,000
1,000
Across open power contacts - - - - - - - - -
1,250
1,250
625
625
All other points - - - - - - - - - - - - - - - - - - -
1,800
1,800
1,350
1,350
Dielectric withstanding voltage (altitude): 1 minute.
28 V dc
115 V ac
Coil to case - - - - - - - - - - - - - - - - -
500
500
Auxiliary contacts - - - - - - - - - - - - -
500
500
All other points - - - - - - - - - - - - - - -
700
700
Maximum contact drop, initial: .150 volt
After life test: .200 volt.
Overload current:
320 amperes (ac). 1/
Rupture current: 400 amperes (ac).
Coil suppression (transient voltage, back emf): 45 V dc maximum.
Duty rating: Continuous.
RFI specification (applicable to coil circuits of ac operated relays): MIL-STD-461.
Part number. M6106/10- (dash number from table I).
Qualification by similarity: See MIL-PRF-6106.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate
the requirements of this document based on the entire content irrespective of the marginal notations and
relationship to the last previous issue.
Referenced documents. In addition to MIL-PRF-6106, this document references the following:
MIL-STD-202
MIL-STD-461
