MIL-PRF-39016/55B
TABLE II. Qualification inspection and sample size.
Single submission
Group submission
M39016/55-002
33 units plus 1 open unit for level M
33 units plus 1 open unit for level M
at C = 0 1/
at C = 0 1/
Qualification inspection as applicable
Qualification inspection as applicable.
2 units, qualification inspection table, Q1,
M39016/55-019
Q2, and shock, vibration, acceleration,
M39016/55-012
terminal strength, and seal.
2 units, qualification inspection table, Q1,
M39016/55-001
Q2, and shock and vibration.
M39016/55-008
2 units, qualification inspection table, Q1,
M39016/55-034
Q2
M39016/55-038
1/ The number of units required for qualification testing shall be increased as required in Q5, table II, MIL-PRF-
39016, if the relay manufacturer elects to test the number of units permitting one or more failures. Prior to
performance of qualification inspection testing, the relay manufacturer shall preselect the sampling plan.
TABLE III. Qualification inspection (reduced testing) and sample size.
Examination or test
Q2 of qualification inspection table (2 units each coil voltage)
Q5 of qualification inspection table (2 units - M39016/55-009)
(2 amperes at 28 V dc)
1 unsealed unit for internal examination (submitted with test report)
8
