MIL-PRF-39016/55B
Coil data: See table I.
Operate time: 4 milliseconds maximum over temperature range with rated coil voltage.
Release time: 8 milliseconds maximum over temperature range from rated coil voltage.
Electrical data:
Insulation resistance: 10,000 megohms minimum (400 Hz load testing required for qualification only).
Dielectric withstanding voltage: 1/
Sea level
Altitude
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure, and all contacts
both in the energized and deenergized position- - - - -
1,000
Between case, frame, or enclosure and coil - - - - - - - -
500
350
Between all contacts and coil - - - - - - - - - - - - - - - - - -
1,000
All terminals
Between open contacts in the energized and
to case
and deenergized positions - - - - - - - - - - - - - - - - -
500
Between contact poles - - - - - - - - - - - - - - - - - - - - - - -
1,000
Diode characteristics: 2/
Maximum negative transient: 1.0 volt.
Coil transient suppression: Applicable.
Semiconductor in-process screening: Applicable; visual inspection of semiconductors shall be in accordance
with MIL-STD-750, method 2073 or method 2074.
Environmental data:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds maximum
for closed contacts and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
(Applicable only for qualification and group C testing.)
Shock (specified pulse): MIL-STD-202, method 213, test condition C (100 G). Contact chatter shall not exceed
10 microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Magnetic interference: Applicable.
Resistance to soldering heat: Applicable.
Acceleration: Applicable.
1/ Connect coil leads together to avoid damage to the diode.
2/ Warning: Reverse polarity on coil terminals will destroy diode.
