MIL-PRF-39016/54D
Qualification inspection:
Qualification inspection and sample size: See table II.
TABLE II. Qualification inspection and sample size.
Single submission
Group submission
22 units plus 1 open unit for level L
M39016/54-011
22 units plus 1 open unit for level L
at C = 0 1/
at C = 0 1/
33 units plus 1 open unit for level M
33 units plus 1 open unit for level M
at C = 0 1/
at C = 0 1/
Qualification inspection as applicable.
Qualification inspection as applicable.
2 units, each PIN, qualification inspection table,
M39016/54-001
Q1.
M39016/54-003
M39016/54-007
M39016/54-009
M39016/54-013
2 units, qualification inspection table, Q1,
M39016/54-006
and shock, vibration, acceleration,
M39016/54-026
terminal strength, and seal.
1/ The number of units required for qualification testing will be increased as required in Q5, table II, MIL-PRF-
39016, if the relay manufacturer elects to test the number of units permitting one or more failures. Prior to
performance of qualification inspection testing; the relay manufacturer shall preselect the sample size.
Referenced documents: In addition to MIL-PRF-39016, this document references the following:
MIL-STD-202
MIL-STD-750
MIL-STD-1285
ASTM B488
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 11
(Project 5945-1298-000)
DLA - CC
Review activities:
Army - AR
Navy - AS, MC, OS, SH
Air Force - 19
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
7
