MIL-PRF-39016/47C
Physical data:
Seal: Hermetic.
Terminals: See figure 1.
Terminal strength: 1.0 ±0.1 pound pull (453 grams).
Solderability: Applicable.
Terminal twist test: Not applicable.
Dimensions and configuration: See figure 1.
Weight: 2.0 grams (0.07 ounce) maximum.
Minimum marking: Applicable.
Life test requirements:
High level: 100,000 cycles.
Low level: 100,000 cycles plus 900,000 cycles mechanical life.
Part or Identifying Number (PIN): M39016/47- (dash number from table I and suffix letter designating failure rate
level).
TABLE I. Dash number and characteristics. 1/ 2/
At +20°C
At +125°C
Coil
Dash
voltage 4/
Coil
Specified pickup
Specified pickup
number
(V dc)
resistance
(latch/reset) value
(latch/reset) value
3/
Rated
Max
ohms
(voltage) 5/
(voltage) 5/
±15%
(V dc)
(V dc)
001
5
7
65
2.5
3.5
002
12
14
375
6.3
9.0
003
24
28
1,500
12.6
18.0
1/ WARNING: When latching relays are installed in equipment, the latch and reset coils should not be pulsed
simultaneously. Coils should not be pulsed with less than the rated coil voltage. The nominal power sensitivity
(rectangular pulses) is 2.0 millijoules at 5 milliseconds. The nominal coil voltage and the pulse width should be a
minimum of three times the specified operate time of the relay.
2/ Relays previously tested or used above 10 mA resistive at 6 V dc maximum or peak ac open circuit shall not be
used for low level applications.
3/ The suffix letter L, M, P, or R to designate the applicable failure rate level that shall be added to the applicable
listed dash number. Failure rate level (percent per 10,000 cycles): L, 3.0; M, 1.0; P, 0.1; R, 0.01.
EXAMPLE, 001L - - - - - - - 002M.
4/ CAUTION: Use of any voltage less than the rated voltage will compromise the operation of the relay.
5/ Allow 10 percent increase in maximum operate voltages after life tests.
