MIL-PRF-39016/47C
Overload (high level only):
Resistive: 2 times rated current.
Inductive: 2 times rated current.
Neutral screen: Applicable.
Coil data: See table I.
Operate time (each coil): 6.0 ms maximum over temperature range with rated coil voltage.
Release time: Not applicable.
Electrical data:
Insulation resistance: 1,000 megohms minimum except the resistance between coil and case at high
temperature shall be 100 megohms or greater. Measure at 100 V dc.
Dielectric withstanding voltage:
Sea level
Altitude
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure, and all contacts- - -
500
Between case, frame, or enclosure and coil(s)- - - - - - -
350
175
Between all contacts and coil(s)- - - - - - - - - - - - - - - - -
500
All terminals
Between open contacts in the set and reset
to case
positions - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
350
Between coils - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
350
Between contact poles - - - - - - - - - - - - - - - - - - - - - - -
500
Environmental data:
Temperature range: -65°C to +125°C.
Magnetic interference: Not applicable.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds maximum
for closed contacts and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts (applicable
to qualification and group C testing only).
Shock (specified pulse): MIL-STD-202, method 213, test condition C (100 g). Contact chatter shall not exceed
10 microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
Coil life: Not applicable.
Resistance to soldering heat: Applicable.
Acceleration: 100 g.
4
