MIL-PRF-39016/43E
After installation of spacer mounting pad, perform the following tests as specified in the qualification inspection
table of MIL-PRF-39016, in the order shown below:
Insulation resistance, dielectric withstanding voltage, static contact resistance, specified pickup, hold, and dropout
values (voltages), coil resistance, operate and release time, contact dynamic characteristics, coil transient
suppression (when specified), solderability, seal, visual and mechanical inspection (external).
Group A testing for relays supplied with spacer mounting pads (-049 through -056 and -065 through -072 shall be
tested as specified below:
Perform seal test immediately preceding the A2 electrical tests. Relay leads shall be formed and the spacer
mounting pad removed before the seal test. After the seal test, the spacer mounting pad shall be rigidly attached
to the relay and the remaining group A tests performed (The seal test is not performed with group A4.)
SUPERSESSION DATA:
Supersession data: See table III.
TABLE III. Supersession data. 1/
Superseded part no.
New part no.
Superseded part no.
New part no.
M39016/43-
M39016/43-
M39016/43-
M39016/43-
001
033
017
033
002
034
018
034
003
035
019
035
004
036
020
036
005
037
021
037
006
038
022
038
007
039
023
036
008
040
024
040
009
041
025
041
010
042
026
042
011
043
027
043
012
044
028
044
013
045
029
045
014
046
030
046
015
047
031
047
016
048
032
048
1/ Dash numbers -001 through -032, .350 inch high cans have been canceled and
superseded by -033 through -048, .375 inch high cans. The .350 inch high cans
are no longer manufactured.
