MIL-PRF-39016/43E
COIL DATA: (See table I).
Operate time: 4.0 ms maximum over temperature range with rated coil voltage.
Release time: 7.5 ms maximum over temperature range from rated coil voltage.
ELECTRICAL DATA:
Insulation resistance: 10,000 megohms minimum at 500 V dc, except the resistance between coil and case at
high temperature shall be 1,000 megohms minimum.
Post intermediate
Dielectric withstanding voltage:
Sea level
current life test
Altitude
V rms (60 Hz)
Sea level
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure and all contacts
in the energized and de-energized positions.
500
500
Between case, frame, or enclosure and coils.
500
500
125
All terminals
Between all contacts and coils.
500
500
Between open contacts in the energized and
to case
de-energized positions.
500
375
Between contact poles.
500
500
Between coils of dual coil relays.
N/A
N/A
DIODE CHARACTERISTICS:
Coil transient suppression: Applicable.
Diode block integrity (perform this test after coil transient suppression test in all inspection tables of MIL-PRF-
39016): With applicable voltage applied to the relay coil circuit in the reverse direction, monitor leakage current
with dc microammeter, oscilloscope, or qualifying activity approved test equipment. Leakage current shall not
exceed the specified value.
Block integrity maximum leakage current: 1 µA at 50 V dc.
Maximum negative transient: 1.0 volt.
Breakdown voltage: 100 V dc minimum at 10 microamperes (µA). (This test may be performed in process or
as final assembly).
Semiconductor in process screening: Applicable, visual inspection of semiconductors shall be in accordance
with MIL-STD-750, method 2073, or 2074.
ENVIRONMENTAL DATA:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds
maximum for closed contacts, and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts
(applicable to qualification and group C testing only).
Shock (specified pulse): MIL-STD-202, method 213, test condition B (75 g's). Contact chatter shall not exceed
10 µs maximum for closed contacts, and 1 µs maximum closure for open contacts.
4
