MIL-PRF-39016/42E
Coil data: (See table I).
Operate time: 4.0 ms maximum over temperature range with rated coil voltage.
Release time: 7.5 ms maximum over temperature range from rated coil voltage.
Electrical data:
Insulation resistance 1/: 10,000 megohms minimum at 500 V dc, except the resistance between coil and case
at high temperature shall be 1,000 megohms minimum.
Sea level
Post intermediate
Dielectric withstanding voltage: 1/
V rms ((60
current life test
Altitude
Hz)
Sea level
V rms
V rms (60 Hz)
(60 Hz)
Between case, frame, or enclosure, and all contacts
500
500
in the energized and deenergized positions:- - - - - - -
500
500
Between case, frame, or enclosure and coil:- - - - - - - -
500
500
125
Between all contacts and coil: - - - - - - - - - - - - - - - - -
All terminals
Between open contacts in the energized and
500
375
to case
deenergized positions:- - - - - - - - - - - - - - - - - - - -
Between contact poles in the energized and
500
500
deenergized positions: - - - - - - - - - - - - - - - - - - -
N/A
N/A
Between coils of dual coil relays - - - - - - - - - - - - - - - -
Diode characteristics 2/:
Maximum negative transient: 1.0 V.
Peak inverse voltage: 100 volts minimum.
Coil transient suppression: Applicable.
Semiconductor in process screening: Applicable, visual inspection of semiconductors shall be in accordance
with MIL-STD-750, method 2073 or 2074.
Environmental data:
Temperature range: -65°C to +125°C.
Vibration (sinusoidal): MIL-STD-202, method 204, contact chatter shall not exceed 10 microseconds maximum
for closed contacts and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts (applicable
to qualification and group C testing only).
Shock (specified pulse): MIL-STD-202, method 213, test condition B (75 g's). Contact chatter shall not exceed
10 microseconds maximum for closed contacts and 1 microsecond maximum closure for open contacts.
1/ Connect coil leads together to avoid damage to the diode.
2/ WARNING: Reverse polarity on coil terminals will destroy diode.
4
