MIL-PRF-39016/42E

Inches

.001

0.03

.002

0.05

.003

0.08

.005

0.13

.014

0.36

.017

0.43

.031

0.79

.047

1.93

.100

2.54

.170

4.32

.275

6.99

.300

7.62

.335

8.51

.370

9.40

.500

12.70

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for general information only.

3. Unless otherwise specified, tolerance is �.010 (0.25 mm).

4. Terminal numbers shown above are for reference only. Numbers do not appear on relay.

5. Relays shall have a plus (+) sign placed on the circuit diagram as shown.

6. Coil symbol optional in accordance with MIL-STD-1285.

7. Circuit diagram shown on part is the terminal view.

8. Mounting pad shall be a polyester film in accordance with MIL-I-631. Type G, class 1.

9. Dash numbers -065 through -072 shall be supplied with a case grounding pin welded to the header

as shown.

FIGURE 2. Dimensions and configuration (relay with mounting pad).
