MIL-PRF-39016/36C
Coil data (each coil): (See table I).
Operate time (latch and reset): 4.0 ms maximum over temperature range with rated coil voltage.
Release time: Not applicable.
Electrical data:
Insulation resistance 1/: 10,000 megohms minimum, except the resistance between coil and case at high
temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage: 1/
Sea level
Altitude
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure, and all contacts ---
750
Between case, frame, or enclosure and coils - - - - - - - -
500
350
Between all contacts and coils - - - - - - - - - - - - - - - - - -
750
All terminals
Between open contacts in the latch and reset
to case
positions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
500
Between contact poles - - - - - - - - - - - - - - - - - - - - - - -
750
Between coils of dual coil relays - - - - - - - - - - - - - - - -
500
Diode characteristics: 2/
Maximum negative transient: 1.0 volt.
Breakdown voltage: 100 V dc at 10 microamperes (µA).
Maximum leakage current: 1 µA at 50 V dc.
Coil transient suppression: Applicable
Semiconductor in process screening: Applicable, visual inspection of semiconductors shall be in accordance
with MIL-STD-750, method 2074.
_______
1/ Insulation resistance and dielectric withstanding voltage tests must always precede all other specified electrical
measurements. Connect all coil terminals together to avoid damage to the diode.
2/ In all tables relating to qualification testing and group A testing, delete coil resistance and substitute the following
tests: (Test each coil individually.) Diode breakdown and block integrity with applicable voltage applied to the
relay coil circuit in the reverse direction, monitor leakage current with dc microammeter or oscilloscope.
Leakage current shall not exceed the specified value.
4
