MIL-PRF-39016/35D
TABLE II. Qualification inspection and sample size. 1/
Single submission
Group submission
24 units plus 1 open unit.
M39016/35-006
24 units plus 1 open unit for
level L at C = 0 2/
level L at C = 0 2/
33 units plus 1 open unit for
33 units plus 1 open unit for
level M at C = 0 2/
level M at C = 0 2/
Qualification inspection as
Qualification inspection as
applicable
applicable
M39016/35-002
2 units qualification
inspection Q1.
M39016/35-001
2 units qualification inspection
Q1, and terminal strength,
resistance to soldering heat,
and seal.
1/ For retention of qualification or extension of qualification to lower failure rate
levels, all life test data accumulated on MIL-PRF-39016/36 may be used in
addition to MIL-PRF-39016/35 data. Prior to performance of retention of
qualification inspection; the relay manufacturer shall preselect the sample size.
2/ The number of units required for qualification testing will be increased as required
in Q5, MIL-PRF-39016, if the relay manufacturer elects to test the number of units
permitting one or more failures. Prior to performance of qualification inspection
testing; the relay manufacturer shall preselect the sample size.
QUALIFICATION INSPECTION (reduced testing): See table III.
If the relays produced for MIL-PRF-39016/35 are similar in construction and design except for the steering diode to
the relays produced for MIL-PRF-39016/36, then reduced testing for qualification of MIL-PRF-39016/35 relays may
be performed concurrent with or subsequent to successful qualification of MIL-PRF-39016/36 relays.
TABLE III. Qualification inspection (reduced testing).
Inspection
2 units each coil voltage - Q1 of qualification
inspection table.
1 unsealed sample unit for internal examination.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate where
changes from the previous issue were made. This was done as a convenience only and the Government assumes
no liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
Referenced documents. In addition to MIL-PRF-39016, this document references the following:
6
