MIL-PRF-39016/35D
Acceleration: Applicable.
PHYSICAL DATA:
Terminal strength:
Pull test: 1.5 0.2 pounds.
Bend test: Not applicable.
Solderability: Applicable.
Dimensions and configuration: See figure 1.
Weight: 7.6 grams (0.27 ounce) maximum.
Minimum marking: Military part number, "J" with the date code (example J0430), circuit diagram,
manufacturer's name or source code.
LIFE TEST REQUIREMENTS:
High level: 100,000 cycles per relay.
Low level: 100,000 cycles plus 900,000 cycles mechanical life.
PART NUMBER: M39016/35- (dash number from table I and suffix letter designating failure rate level).
TABLE I. Dash number and characteristics. 1/ 2/
Coil
Specified pickup
Mount
Terminal
Coil voltage
resistance
Dash
(latch/reset)
at +25C
(V dc)
value (voltage)
(V dc) 5/
tolerance
25C
125C
10%
Rated 4/
Max
(ohms)
-001
No mount
Wire lead (SP)
6.0
7.2
37
2.6
3.8
-002
No mount
Wire lead (SP)
12.0
14.5
145
5.2
7.6
-003
No mount
Wire lead (SP)
26.5
35.0
975
13.5
18.0
-004
Flange
Solder lug
6.0
7.2
37
2.6
3.8
-005
Flange
Solder lug
12.0
14.5
145
5.2
7.6
-006
Flange
Solder lug
26.5
35.0
975
13.5
18.0
1/ Each relay possesses high level and low level capabilities. However, relays previously tested or used above 10 mA
resistive at 6 V dc maximum or peak ac open circuits not recommended for subsequent use in low level
applications.
2/ WARNING: When latching relays are installed in equipment, the latch and reset coils should not be pulsed
simultaneously. Coils should not be pulsed with less than the rated coil voltage.
3/ The suffix letter L, M, P, or R to designate the applicable failure rate level shall be added to the applicable listed
dash number. Failure rate level (percent per 10,000 cycles): L, 3.0; M, 1.0; P, 0.1; R, 0.01. Example, 001L - - - -
006R.
4/ CAUTION: Use of any coil voltage less than the rated voltage will compromise the operation of the relay.
5/ A 10% increase in latch and reset voltages is allowed during and after rated life.
5
