MIL-PRF-39016/35D
COIL DATA (Each coil): (See table I).
Operate time (latch and reset): 4.0 ms maximum over temperature range with rated coil voltage.
Release time: Not applicable.
ELECTRICAL DATA:
Insulation resistance 1/: 10,000 megohms minimum, except the resistance between coil and case at
high temperature shall be 1,000 megohms minimum.
Dielectric withstanding voltage:
Sea level
Altitude
V rms (60 Hz)
V rms (60 Hz)
Between case, frame, or enclosure and all contacts
in the energized and de-energized positions.
750
350
Between case, frame, or enclosure and coils.
500
All terminals
Between all contacts and coils.
750
to case
Between open contacts in the latch and reset
positions.
500
Between contact poles.
750
Between coils of dual coil relays.
500
DIODE CHARACTERISTICS: 2/
Maximum negative transient: 1.0 volt.
Coil transient suppression: Applicable.
Semiconductor in process screening: Applicable, visual inspection of semiconductors shall be in accordance
with MIL-STD-750, method 2074.
ENVIRONMENTAL DATA:
Temperature: -65C to +125C
Vibration (sinusoidal): MIL-STD-202, method 204. Contact chatter shall not exceed 10 microseconds maximum
for closed contacts, and 1 microsecond maximum closure for open contacts.
Vibration (random): MIL-STD-202, method 214, test condition IG. Contact chatter shall not exceed 10
microseconds maximum for closed contacts, and 1 microsecond maximum closure for open contacts (applicable
to qualification and group C testing only).
Shock (specified pulse): MIL-STD-202, method 213, test condition C (100 g's). Contact chatter shall not exceed
10 s maximum for closed contacts, and 1 s maximum closure for open contacts.
Magnetic interference: Applicable.
Resistance to soldering heat: Applicable.
1/ Connect each set of coil terminals together to avoid damage to the diodes.
2/ WARNING: Reverse polarity on coil terminals will destroy the diode.
