MIL-PRF-39016/30F
1/ Each relay possesses high level and low level capabilities. However, relays previously tested or used above 10
mA resistive at 6 V dc maximum or peak ac open circuits not recommended for subsequent use in low level
applications.
2/ WARNING: When latching relays are installed in equipment, the latch and reset coils should not be pulsed
simultaneously. Coils should not be pulsed with less then the nominal coil voltage and the pulse width should
be a minimum of three times the specified operate time of the relay. If these conditions are not followed, it is
possible for the relay to be in the magnetically neutral position.
3/ The suffix letter L, M, P, or R to designate the applicable failure rate level shall be added to the applicable listed
dash number. Failure rate level (percent per 10,000 cycles): L, 3.0; M, 1.0; P, 0.1; R, 0.01. Example, 025L - -
- - - -072R.
4/ 1.500 leads are inactive for new design.
5/ Relays supplied with spreader mounting pads (-061 through -072) shall have the spreader mounting pad rigidly
attached.
6/ CAUTION: The use of any coil voltage less than the rated coil voltage will compromise the operation of the
relay.
7/ Coil resistance not directly measurable at relay terminals. When rated voltage is applied to coil terminals, the
coil circuit must be within the limits shown. Measure at 25°C at nominal voltage for 5 seconds maximum.
8/ Relays are supplied with a case grounding pin welded to the header (see figure 2).
9/ Delete "Coil resistance" and substitute "Coil current" test in all inspection tables of MIL-PRF-39016.
QUALIFICATION INSPECTION:
Qualification inspection and sample size: See table II.
TABLE II. Qualification inspection and sample size. 1/
Single submission
Group submission
M39016/30-053
18 units plus 1 open unit for
18 units plus 1 open unit for
level L at C = 0 1/
level L at C = 0 1/
33 units plus 1 open unit for
33 units plus 1 open unit for
level M at C = 0 1/
level M at C = 0 1/
Qualification inspection as
Qualification inspection as
applicable
applicable
M39016/30-049
2 units each PIN
M39016/30-050
Qualification inspection, Q1.
M39016/30-051
M39016/30-052
M39016/30-054
M39016/30-055
M39016/30-056
M39016/30-057
M39016/30-058
M39016/30-059
M39016/30-060
M39016/30-078
1 unit terminal strength and
terminal solderability
1/ The number of units required for qualification testing shall be increased as required in Q5,
MIL-PRF-39016, if the relay manufacturer elects to test the number of units permitting
one or more failures. Prior to performance of qualification inspection testing; the relay
manufacturer shall preselect the sampling plan.
